Photocatalyst coating metal
Description
Traditional photocatalyst coating with organic binder should be short life time, because photocatalyst decompose organic binder. GiantNano photocatalyst coating with inorganic binder on foaming ceramics is stable under UV light exposure, even UVC and UVB light.
GiantNano Photocatalyst coating foaming ceramics can decompose total volatile organic compound and harmful gases, such as formaldehyde, methanol, NOx, bacteria, virus….
Feature
- High decomposition rate
- Long life time
- Easy to clean
- Foam porosity can be customized
Specification
| Item | Result |
| Appearance | Grey |
| Porosity of foaming(PPI) | 20~40 |
| Density (g/cm2) | 200~500 |
| Thickness of foaming nickel (mm) | 1~5 |
| Thickness of photocatalyst coating (um) | 20~100 |
Process condition
| Item | PSG | Mark |
| Solution temperature(°C) | 23~27 | |
| Coating method | Spray/Roller | Dry film thickness >100nm Higher dry film thickness, higher UV-cut percentage |
| Coating environment-temperature (°C) | 23~27 | |
| Coating environment-humidity (%) | 50~80 | |
| Curing temperature (°C) | 300~600 °C 30min |
Performance
| Item | PSB-OX | PSG-PX | PSG-HX | Test method | reference |
| Adhesion | 5B (Under 5 days sunlig ht) | 5B | 5B | 3M scotch 600 tape | ASTM3359 |
| water contact angle | <20° | <10° | <20° | Goniometer | |
| Pencil hardness | 5H (Under 5 days sunlight) | 7H | >8H | 1kg | ASTM3363 |
| Gloss 60° | >170 | >170 | >170 | Gloss meter | |
| Sterilization | >80% | >80% | >80% | FIRDI(visible light) | TN-002 |
| Sterilization | >99.99% | >99.99% | >99.99% | NCKU (UV light) | TN-002 |
